1 to 1 Debugger & Programmer



Nu-Link can program and debug the NuMicro® Family of Microcontrollers. Based on different features, there are five types to choose from : Nu-Link, Nu-Link-Pro, Nu-Link2-Pro sold separately,and Nu-Link-Me & Nu-Link2-Me connected to NuMaker.
All Nu-Link debugger/programmer support :
• Embedded SRAM and Flash read/write
• Direct register control in real-time
• Hardware/software breakpoints insert
• Step-run program under debug mode
• Semihost function under debug mode

In addition, Nu-Link2-Pro、Nu-Link、Nu-Link-Me and Nu-Link2-Me additionals to support Virtual COM (VCOM) Port function

  Nu-Link2-Pro Nu-Link-Pro Nu-Link Nu-Link2-Me Nu-Link-Me
  Nu-Link2-Pro

Nu-Link-Pro

Nu-Link Nu-Link2-Me Nu-Link-Me
Debugging
Online Programming
Offline Programming
VCOM Port
(Nu-Link V3.2 and above are supported)
Bus Monitor
ETM
SWD I/O Voltage
1.8/2.5/3.3/5.0

1.8/2.5/3.3/5.0

5.0

1.8/3.3/5.0

3.3/5.0
Upgrade UART/SPI/I²C/ RS-485/CAN/ USB pen drive/MicroSD     UART UART
