NAU83R15YG
NAU83R15YG 是一款高效率的单声道 D 类音讯放大器，无需滤波器，以及能够在 4 Ω 负载下输出功率高达 3.2 W。本装置提供晶片使能引脚，并能提供极低的待机电流，I²S 音频输入，快速启动时间。
NAU83R15YG 非常适合可携式应用。此装置具备 91% 效能，PSRR 80 dB，超低静态电流，以及卓越的 EMI 效能等先进功能。
目标应用:
- 游戏控制器
- 无线(虚拟现实)耳机
- 智能遥控器
- 笔记型电脑 / 平板电脑
- 个人媒体播放器
- 超声波扬声器
Key Features:
| • | 音频输入 | |
| - | 数字音频接口: I²S / PCM 输入 | |
| - | 引脚选择: I²S 左或右声道 | |
| - | 引脚选择: PCM 时序 | |
| - | 采样率: 8 ~ 96 kHz | |
| - | 80 dB PSRR @ 217 Hz | |
| • | 音频输出 | |
| - | 强大的 D 类单声道放大器 | |
| - | 3.2 W (4 Ω @ 5V, 10% THD+N) | |
| - | 1.76 W (4 Ω @ 4.2V, 1% THD+N) | |
| - | 1.8 W (8 Ω @ 5V, 10% THD+N) | |
| - | 1.0 W (8 Ω @ 4.2V, 1% THD+N) | |
| - | 低输出噪声: 12 µVRMS | |
| • | 进阶功能 | |
| - | 低电流关断模式以及待机模式 | |
| - | 开关噪声抑制: 26 µVRMS | |
| • | 工作特性 | |
| - | 电压范围: 2.5V ~ 5.25V | |
| - | 温度范围: -40°C ~ +85°C | |
| • | 封装 | |
| - | QFN-20 (4 x 4 mm) | |
