NAU8421YG
NAU8421YG 是一款高品质 24 位双声道 DAC，具有 8Vpp 差分模拟输出能力，128 dB SNR 和 -99 dB THD+N。该设备包括一个 I²C 控制接口，具有附加引脚可选功能和独立操作。
NAU8421YG 采用 3.3V 数字 I/O 电源电压和5V 模拟电源电压运作。此外，NAU8421YG还包括自动时钟侦测序列，可实现平稳的启动和关闭控制。这使得系统整合快速且有效率。
目标应用:
| • | 电子乐器 | |
| • | 数字音频系统 | |
| • | 游戏主机 | |
主要特点:
| • | 音频输入 | |
| - | 数位音频接口: I²S / PCM | |
| - | 工作采样率: 8 kHz ~ 192 kHz | |
| • | 音频输出 | |
| - | 最大输出电压范围: 8.3Vpp | |
| - | SNR: 128 dB | |
| - | THD+N: -99 dB | |
| • | 进阶功能 | |
| - | 自动时钟侦测 | |
| - | 高系統噪音抑制 | |
| • | 工作特性 | |
| - | 电压范围 (VDDB): 3.0V ~ 5.5V | |
| - | 电压范围 (VDDA): 3.0V ~ 5.5V | |
| - | 温度范围: -40°C ~ +85°C | |
| • | 封装 | |
| - | QFN-32 (5 mm x 5 mm) | |
